900 Series Low Cost Coating Thickness Gauges |
Measuring Range 0-40.0 mils (0-999 m)
DCF-900 Coating Thickness Gauges measures the thickness of paint, plating, coatings and galvanizing on iron or steel...more accurately, dependably and economically!
DCN-900 Coating Thickness Gauges measures the thickness of paint coatings, anodize on aluminum, brass, zinc, stainless steel and other non-ferrous metals. |
 Features of the 900 Series Coating Thickness Gauge
 Dependable accuracy over the entire range of the gauge, not just at "calibration check" points. | | Keypad-selectable English or metric units. | | Continuous reading update detects soft coatings as probe tip "sinks" into them. | | The DCF-900 and DCN-900 Coating Thickness Gaugesinclude the gauge and probe, a bare test plate, two precision calibration shims & instructions, all in a foam-fitted carrying case. | | Calibration to NIST standards is available upon request. |
| | Remote probe permits easy access for difficult, hard-to-reach places. | | Longer lasting, driftless calibration... Set it and forget it for long periods of time and from job to job | | Very reliable operation... Consistent, repeatable measurements | | Excellent results with thin substrates... As thin as 0.005" (10 m) |
|
Photo Gallery of the 900 Series Coating Thickness Gauges click any photo to enlarge
| DCF-900 Testing Plastic Shim on bare steel test plate |
Related Products of the 900 Series Coating Thickness Gauges
|
NTS
NIST Certified Plastic Shims |  |
| | | _ |
|
TS-5CG
Commercial Grade Shim Set |  |
| |
Measuring Limits of the 900 Series Coating Thickness Gauges
 | Minimum Radius for Convex Surfaces | 0.375" (9.5 mm) | | Minimum Radius for Concave Surfaces | 2.5" (63.5 mm) |  | Minimum Headroom | 2.5" (63.5mm) |  | Minimum Sample Diameter | 0.5" (13 mm) |  | Minimum Substrate Thickness - F | 0.020" | | Minimum Substrate Thickness - NFe | NA |
Complete Kit of the 900 Series Coating Thickness Gauges
| | | The 900 Series Gauges are supplied as a complete kit including gauge, ferrous or non-ferrous zero plate, 2 plastic test shims and instruction manual in a foam fitted, hard plastic carrying case. |
 |
Specifications of the 900 Series Coating Thickness Gauges
| Range: | 0.1-40.0 mils (0-999 m) | | Resolution: | 0.1 mil (1 m) | | Accuracy: | 0-10 mils: 0.1 mil
10-40 mils: 1% of reading | | Probe: | DCF-900: Monopolar, magnetic induction, 0.4" (10 mm) dia., spring-loaded, with V-notched shell and 28" (70 cm) cable
DCN-900: Eddy current, 0.4" (10mm) dia., spring-loaded, with v-notched shell and 28" (70cm) cable | | Battery/Life: | 9 V alkaline/approx. 6 months normal use, with auto shutoff after 90 seconds of non-use. | | Dimension: | 5.7" x 3.1" x 1.5"
(145 x 79 x 38 mm) | | Weight: | 9 oz. (250 g) | | Temperature Limits: | Material: 15 to 140 F (-10 to 60 C)
Ambient: 32 to 125 F (0 to 50 C) | | Warranty: | One (1) year |
