PosiTest G (0-200 microns) Magnetic Pull-Off Thickness Gauge
Price: $ 350.00
PosiTest Magnetic Pull-Off Coating Thickness Gages for Non-Magnetic Coatings on Steel
Banana-Type Type Coating Thickness Gauge
Available as PosiTest FM, F, GM and G Models
Magnetic pull-off thickness gauges for the Non-destructive measurement of non-magnetic coatings (paint, enamel, plastic, galvanizing, metalizing, plating, etc.) on STEEL.
Features of the PosiTest Magnetic Pull-Off Coating Thickness Gauge |
|
Accuracy - Highly wear resistant Carbide Probe for longest life and continuous accuracy
- Modern and up-to-date gauge Scale Ranges fit all applications
- The PosiTest Magnetic Pull-Off Thickness Gauge conforms to national and international standards
- Certificate of Calibration showing traceability to N.I.S.T. included with every gauge
Durability - Extra rugged gauge housing, not affected by mechanical shock, water, acid or solvents
- Unique overall gauge design, fully supported, positive positioning, no pivoting tendencies during measurement
- Gauge can be used fully supported or with only the front probe area contacting the surface
- Functions on a permanent rare-earth cobalt magnet, no battery
- Explosion Proof - Refinery safe
- The PosiTest Magnetic Pull-Off Thickness Gauge has 1 year warranty
Easy To Use - The PosiTest Magnetic Pull-Off Thickness Gauge features Positive visual and audible indicators to designate when thickness reading is established
- "V" grooves in probe housing and Gauge base allow correct positioning on cylindrical objects
- The PosiTest Magnetic Pull-Off Thickness Gaugeis Compact, lightweight, precisely balanced, Independent of gravity - Gauge can be used in any position
- GO / NO-GO button can be pre-set for rapid measurement
- Probe contact and dial rotation all in a one-finger operation
- Gauge is furnished with wrist strap, neck strap and instructions in a high quality leather case with belt loops for your convenience.
|
Available Models of the PosiTest Magnetic Pull-Off Coating Thickness Gauge |
|
For hot dip galvanizing, hard chrome metalizing, paint, enamel, plastic coatings on steel. | For electroplating, thin paint films, phosphating on steel. |
Scale FM: | 0-80 mils | Scale GM: | 0-8 mils | Tolerance: | 0.2 mils up to 4 mils
5% of the reading over 4 mils | Tolerance: | 0.04 mils up to 0.8 mils
5% of the reading over 0.8 mils |
Scale F: | 0-2000 m | Scale G: | 0-200m | Tolerance: | 5 m up to 100 m
5% of the reading over 100 m | Tolerance: | 1 m up to 20 m
5% of the reading over 20 m |
|
|
|
